Automatic stirrup bender from coil
Smart 13 Coil

Single direction automatic stirrup bender from coil for the production of stirrups and cut-to-size bars using wires up to Ø13 mm (#4).
Driven by electric servo motors. Possibility to produce upwards bends up to 90°.

Smart 13 Coil stirrup benders are equipped with a device for the production of "bottlenecks".

Technical data

    Processed wire type
    Single strand

    Double strand

    Pulling speed
    HS version
    Bending speed
    Average power consumption

    Coil
    1 Ø 4,2÷13 mm (#4)

    2 Ø 4,2÷10 mm (#3)

    130 m/min (430 ft/min)
    Not available
    1110°/sec - Single direction
    2 kWh

As the products are in continuous development,
the technical specifications and images are purely by way of example and not binding.
